• Model NO.：wire mesh belt
• Material of Belt：Stainless Steel 304 310 316
• Wire Dia：1-6mm
• Grade：Food
• Transport Package：Wooden Case
• Specification：1x20m
• Trademark：hxmesh
• Origin：China
• HS Code：73141400
• Production Capacity：1000m,Day

https://jaclmery.en.made-in-china.com/product-list-1.html
Providing creative woven metal wire belting solutions in a variety of industries.


We are a complete company with the following core competencies:
- Metal Wire Mesh Conveyor Belt Fabrication
- Flat Wire Belt Manufacturing
- Round Wire Belt Manufacturing
- Rod Belt Manufacturing
- Spiral Wire Belt Manufacturing
Specification for Wire Mesh Conveyor Belt Typical specification (nominal size)SpecificationWeight(kg/m²)SpecificationWeight(kg/m²)K2-40-S0-6.0-5.015.0K2- 6- 9-2.0-2.016.1K2-25-30-5.0-5.023.7K2- 10-15-2.0-1.87.2K2-30-40-5.0-4.012.7K2- 6- 9-1.8-1.812.6K2-20-25-5.0-4.021.5K2- 10-15-1.8-1.65.6K2-15-20-4.0-4.025.4K2- 7-10-1.8-1.68.7K2-20-2S-4.0-3.414.4K2- 5- 7-1.6-1.612.7K2-25-30-4.0-3.210.4K2- 8-12-1.6-1.45.5K2-15-20-3.4-3.216.0K2- 5- 7-1.4-1.49.3K2-20-25-3.4-3.010.7K2- 9-13-1.6-1.23.9K2-15-20-3.2-3.013.9K2- 6- 9-1.4-1.25.6K2-10-15-3.2-3.021.9K2- 4- 6-1.2-1.28.5K2-15-20-3.0-2.610.6K2- 6- 9-1.2-1.03.8K2-10-15-2.6-2.615.3K2- 4- 6-1.2-1.06.2K2-15-20-2.6-2.38.0K2- 3- 4-1.0-1.08.6K2-10-15-2.6-2.312.3K2- 4- 6-1.0-0.94.7K2-8-12-2.3-2.315.3K2- 3- 4-1.0-0.97.2K2-12-18-2.3-2.07.4K2- 4- 5-1.0-0.84.3K2-8-12-2.3-2.012.1K2- 3- 4-0.9-0.85.5 wire belt :


Material for wire mesh belt:
Stainless steel 304;
Stainless steel 316;
Stainless steel 310;
High carbon steel;
Other materials.
Flat flex wire belt
Flat Flex Conveyor Belts are also known as Enrober conveyor belts. The flat flex conveyor belt is constructed by several loop wires and then be formed a different edge. The simple structure makes it economical and lightweight. It can help to save costs and reduce downtime. Flat Flex Conveyor Belts are used in many industries. The belts have a lightweight single-layer construction and are positively driven by sprockets. Flat Flex Conveyor Belts are made of stainless steel wire of spring wire. Wire diameters vary from 0.8 to 3.0 mm. Pitches from 4 mm until 2000 mm, and belt widths from 10 mm until 3 meters, also we can make all the (non-standard) dimensions too. The Flat Flex Conveyor Belts have an open structure (70 - 86 % open) and are frequently used in cooling, baking, drying, heating, decorating, battering and packing machines for light products. The Flat Flex Conveyor Belts can be made for straight conveyors and for curve conveyors.

Application for wire mesh belt:
- Equipment for blanching vegetables and potatoes.
- Pasteurisation tunnels for the canning industry and breweries.
- Dryers, fryers and baking ovens for french fries and snacks.
- Cooling and freezing tunnels for potatoes, french fries, vegetables, meat, fish and bakery products.
- Industrial washing and drying tunnels.
- Food processing
- Confectionery
- Baking
