Conveyor & Parts

Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry

Rizhao Dongyang Beite Machinery Technology Co., Ltd.
  • Material:Carbon Steel
  • Surface Treatment:Polishing
  • Motor Type:Frequency Control Motor
  • Installation:Multi-Layer
  • Pulley Type:Drive Pulley Bend Pully Head Pulley Tail Pulley
  • Transport Package:Wooden Box

Base Info

  • Specification:102mm-1800mm
  • Trademark:DYBT
  • Origin:Shandong
  • HS Code:8431390000
  • Production Capacity:10PC,Day

Description

Basic Info.

Specification 102mm-1800mm Trademark DYBT Origin Shandong HS Code 8431390000 Production Capacity 10PC/Day

Product Description

Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
Rizhao Dongyang Beit Industrial Technology Co., Ltd. is located in the beautiful coastal city of Rizhao, Shandong Province. The company covers an area of 10,000 square meters, and currently has more than 200 employees.Is a collection of research and development, production, sales and service in one of the high-tech technology enterprise.Our company has more than 20 years of experience in metallurgical and mine transportation equipment development and development, can provide all kinds of metallurgical enterprises and mine transportation engineering transportation engineering design, transportation equipment installation and debugging, personnel training, after-sales maintenance and other one-stop service, Dongyang bet is dedicated to building global professional metallurgical and mining transportation equipment suppliers, therefore, we do excellence in every link.We implement strict whole-process quality management for every product entering and leaving the factory, and took the lead in passing the ISO9001:2015 and CE international quality certification in the same industry.


Applicationrecycling industry
power industry
parcel transport industry
petro industry
coal mining industry
cement concrete industry
machining industry
Pipe/Tube/Shell

The tail(bend) pulley is used for changing the direction of the belt running or increasing the wrap angle between the conveyor belt and the driving pulley.

As per different carrying capacities, the tail(bend) pulley can be divided into three categories: light duty, medium duty and heavy duty. The shift of bearing aperture can be 50~100 mm,120~180 mm and 200~260 mm. And the structure is the same with the driving pulley.

The tail(bend) pulley is usually installed at the tail part or the vertical take-up equipment part when the belt direction need to 180°bending. It will be installed above the take-up equipment part while 90°bending .The pulley, which is used for extending the contact surface, is usually used for below or equal to 45°bending.

The surface treatment of the tai(bend) pulley can be smooth steel or flat rubber lagging.



Shaft/AxisMaterial:carbon steel ,stainess steel
BearingBig roving crack, deep groove ball with double sealing
WeldingPipe and bearing housing with automatic welding
SurfaceSmooth steel color surface,  rubber lagging surface
ColorRed,green,blue or as require
Working life≥30000 hours
StandardGB,ISO,DIN,CEMA,JIS
Specialcan be customized according to customer or design for customer
Supply Ability50 pcs per day
CertificateISO9001:2008, BV, SGS

 Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining IndustryDrive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining IndustryDrive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry

Design Details
Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
Example of Case
Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
Our Certificate

Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining IndustryOur Factory Inside

Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining IndustryDrive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
Factory Out Side
Drive/End Pulley for Recycling Industrypower Industryparcel Transport Industrypetro Industrycoal Mining Industrycement Concrete Industry Machining Industry
