• Model NO.：SYCP plate conveyor
• Condition：New
• Name：Chain Plate Conveyor
• Maximum Weight of Goods：800 Kg,M2
• Type：Linear,Curve
• Frame Material：Stainless Steel,Carbon Steel
• Belt Material：SUS304,Carbon Steel,Hot Plastic
• Straight Chain Plate Width：63.5, 82.5, 101.6, 114.3, 152.4, 190.5, 254, 304.8
• Turn Chain Plate Width：82.5, 114.3, 152.4, 190.5, 304.8mm
• Belt Width：200 mm~800 mm
• Length：Customized
• Height：Customized
• Speed：Fixed,Variable
• Speed Range：0.4 M ~ 15 M,Min
• Working Temperature：-20deg ~ + 120deg
• Caster：Stationary,Movable
• Transport Package：Plywood Case by Sea
• Specification：Customized
• Origin：China
• Production Capacity：1000sets,Year

Basic Info.

Model NO. SYCP plate conveyor Condition New Name Chain Plate Conveyor Maximum Weight of Goods 800 Kg/M2 Type Linear/Curve Frame Material Stainless Steel/Carbon Steel Belt Material SUS304/Carbon Steel/Hot Plastic Straight Chain Plate Width 63.5, 82.5, 101.6, 114.3, 152.4, 190.5, 254, 304.8 Turn Chain Plate Width 82.5, 114.3, 152.4, 190.5, 304.8mm Belt Width 200 mm~800 mm Length Customized Height Customized Speed Fixed/Variable Speed Range 0.4 M ~ 15 M/Min Working Temperature -20deg ~ + 120deg Caster Stationary/Movable Transport Package Plywood Case by Sea Specification Customized Origin China Production Capacity 1000sets/Year

Product Description

Horizontal Carbon Steel Plate Scraper Belt Conveyor Manufacturer
Horizontal Carbon Steel Plate Scraper Belt Conveyor Manufacturer
Horizontal Carbon Steel Plate Scraper Belt Conveyor Manufacturer
--Conveyor Industry trends
In modern times, logistics automation standard is beginning to be the symbol of business modernization in different fields, such as food industry, pharmaceuticals industry,logistics, chemical industry etc, so conveyor machinery is more and more important as automatic equipment.

--Company introduction:
We Zhengzhou Syoung Machinery Co.,Ltd is specialized in manufacturing and exporting conveyor equipment for many years.
We have professional technical engineer team, which have more than 20 years experience in conveyor solutions for different fields.
We are engaged in customizing different size conveyor as clients' specifications and requirements, which received good feedback from our clients.

--Chain plate belt conveyor Functions:
Chain plate conveyor can meet the requirement of single transportation of beverage labeling filling and cleaning equipment.
--Chain plate  belt conveyor Application:
Widely used for automatic transmission, distribution and packaging in food, tin cans, drugs, beverage, cosmetics, cleaning products, paper products, spices, dairy and tobacco.

--Chain plate material:carbon steel, stainless steel, hot plastic chain etc.
--Chain plate specifications:
Straight chain plate width can be 63.5, 82.5, 101.6, 114.3, 152.4, 190.5, 254, 304.8;
Turn chain plate width can be 82.5, 114.3, 152.4, 190.5, 304.8.

--Chain plate belt conveyor Main technology parameters.
◊Chain pitch: 25.4 mm ~203.2 mm
◊Plate chain conveyor width: 200 mm~800 mm (width >800 mm, it can use double plate chains)
◊Transportation speed: 0.4 m ~ 15 m/Min
◊Maximum weight of goods: 800 kg/m2
◊Metal plate chain working environment temperature:-20 °C ~ + 120 °C

--More details of chain plate belt conveyor

--Chain plate belt conveyor Features: .
1, The surface of chain conveyor is flat and smooth, and the friction is less.The material can pass the transmission line stably.
It can transport glass bottle, PET bottles, ring-pull cans and all kinds of bags.
2, It has large carrying ability, and carry large load such as electric car, motorcycle, generators and other industries.
3, The conveying speed is accurate and stability, can guarantee the precise synchronization conveying.
4, The chain conveyor generally can be directly cleaned with water or soaked in water, which can satisfy the health requirements of food and beverage industry .
5, The equipment layout is flexible, so it can complete level, inclined and turn conveying in a transmission line.

--Packing&Shipping:
Generally packed in Plywood case.
Shipment within 10~20 working days after the advance/full payment.
--Our Service:
Our warranty is 12 months from the machine leaving factory.
We have professional engineer teams to solve the technological problems for our client.
We have installed all the units well, so this conveyor is very convenient for transport.
In order to let you free from adjusting trouble,we have done it for you before shipping.
We'd like to spare no effort to provide better service.

Notes: according to the needs of your product we can select different width, different shapes of chain plate to complete requirements of flat conveying, flat turning, elevating, dropping.
