Conveyor & Parts

18 Steel Cord Rubber Conveyor Belting with Wear/Abrasion Resistance

Qingdao Zhonghua Yongli New Material Co., Ltd.
  • Type:NN150
  • Material:Steel
  • Inside Material:Polyester
  • Feature:Oil-Resistant, Acid And Alkali Resistant, Tear-Resistant, Heat-Resistant
  • Tensile Strength:Common
  • Colour:Black

Base Info

  • Model NO.:st200XBW2000X12000M
  • Rubber Cover Grade:14-25MPa
  • Structure:Steel Cord +Rubber Cover
  • Width:400-4000mm
  • Thickness:6-40mm
  • Lead Time:16-66 Working Days
  • Port of Loading:Qingdao Port
  • MOQ:100m
  • Max Packing Length Per Roll:700m
  • Annual Capacity:15000000sqm
  • OEM or Not:OEM Available
  • Transport Package:Plastic Sheet
  • Specification:ST630-ST5400
  • Trademark:ZHYL
  • Origin:China
  • HS Code:4010120000
  • Production Capacity:1500m,Day

Description

Basic Info.

Model NO. st200XBW2000X12000M Rubber Cover Grade 14-25MPa Structure Steel Cord +Rubber Cover Width 400-4000mm Thickness 6-40mm Lead Time 16-66 Working Days Port of Loading Qingdao Port MOQ 100m Max Packing Length Per Roll 700m Annual Capacity 15000000sqm OEM or Not OEM Available Transport Package Plastic Sheet Specification ST630-ST5400 Trademark ZHYL Origin China HS Code 4010120000 Production Capacity 1500m/Day

Product Description

Steel cord conveyor belt:

  Belt Strength(ST-NO. )  Max cord diam(mm)  CompositionPitch(mm)   Standard working tension(N/mm)Standard Thickness t1t2   (mm)  Tape reference quality  (kg/  m2 )Min. pulley diam(mm) Cord strength    KN/piece
  ST-630  3  K6X7+IWS  10  90  5X5  19.1  800  6.93
  ST-800  3.5  K6X7+IWS  10  110  5X5  20.6  800  8.8
  ST-1000  4  K6X7+IWS  12  140  6X6  24.7  800  13.2
  ST-1250  4.5  K6X7+IWS  12  175    6X6  25.4  800  16.5
  ST-1600  5  K6X19+IWS  12  225    6X6  26  1000  21.12
  ST-2000  6  K6X19+IWS  12  285    8X6  30  1000  26.4
  ST-2500  7.2  K6X19W+IWS  15  355    8X6  32.2  1250  41.25
  ST-3150  8.1  K6X19W+IWS  15  450  8X8  35.7  1400  51.98
  ST-3500  8.6  K6X19W+IWS  15  500  8X8  44.9  1500  57.7
  ST-4000  8.9  K6X19W+IWS  15  570  8X8  46.6  1600  66
  ST-4500  9.7  K6X19W+IWS  16  645  8X8  49  1800  79.2
  ST-5400  11.3  K6X19W+IWS  17  760  9X9  57.5  2000  101

We can make our products on DIN22102/ DIN22131/M668.
width: 400mm-2400mm;
thickness :6mm-30mm
length:20m-1000m;
rubber cover tensile strength: 8mpa -25mpa.
fabric tensile : Ep80-ep400.

packages: plastic sheets  or  according to customer enquirments.
shipping: by containers , if customer need steel pallets, we can offer it.

quality guarranty period:
1.   general belts,  guarranty period is 12months
2.   heat resistant belt : 200c  only 6months, up 250c, guarranty period is 3 months.
3.   steel cords belts guarranty period is 36months.
4.   we can offer technical references for using,
5.   if  products got not manue demaged , we will send engineer to fix or  repoduce the products during our gurranty period.

OUR SERVICES:


1. Pre-sales service

* Inquiry and consulting support
* Sample testing support
* View our factory

2. After-sales service

* We provide 24hour/7days after-sales service
* Regularly visit our client and keep quality tracking:

1.   we can offer technical references for using,
2.   if  products got not manue demaged , we will send engineer to fix or  repoduce the products during our gurranty period.


3. One year warranty

No damage to human factors, one year warranty, life-long maintenance.

1.   general belts,  guarranty period is 12months
2.   heat resistant belt : 200c  only 6months, up 250c, guarranty period is 3 months.
3.   steel cords belts guarranty period is 36months. ;
TRANSPORTATION DETAILS:
  1. packages: plastic sheets  or  according to customer enquirments.
  2. shipping: by containers , if customer need steel pallets, we can offer it.
