Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine

Xinxiang Hengyu Machinery Equipment Co., Ltd.
  • Structure：Conveyor System
  • Material：Stainless Steel
  • Material Feature：Oil Resistant, Heat Resistant, Fire Resistant
  • Application：Chemical Industry, Grain Transport, Powder,Particle
  • Condition：New
  • Product Name：Spiral Vibrating Elevator

Base Info

  • Model NO.：HYC-800
  • Convey Hight：up to 6m
  • Conveying Capacity：up to 5t,H
  • Conveying Groove Diameter：900mm
  • Speed：960r,Min
  • Weight：2100kg
  • Power：2*3.0kw
  • Conveyor Width：224
  • Double Amplitude：6-10mm
  • Transport Package：Be Packed in Standard Exporting Wooden Case
  • Specification：as request
  • Trademark：Hengyu
  • Origin：Xinxiang, China
  • Production Capacity：100 Sets Per Months

Description

Type

Lifting Capability(t/h)

Diameter of spiral chute

(mm)

Lifting height

(m)

Speed

(rpm)

Double amplitude

(mm)

Power

(kw)

HYC300

Up To 1.0

300

≤2.0

960

6-7

2*0.4

HYC500

Up To 2.0

500

≤3.0

960

6-8

2*0.75

HYC550

Up To 3.0

550

≤3.5

960

6-8

2*1.5

HYC600

Up To 3.0

600

≤4.0

960

6-7

2*1.5

HYC800

Up To 4.0

800

≤4.5

960

6-8

2*2.2

HYC850

Up To 4.0

850

≤5.0

960

6-9

2*2.2

HYC900

Up To 3.5

900

≤6.0

960

6-9

2*3.0

HYC950

Up To 4

950

≤8.0

960

6-9

2*3.7


Product Detail
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine

Product Show
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine
Particle Powder Vertical Vibrator Rotating Conveyor Spiral Screw Feeder Machine
