Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor

Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.
  • After-sales Service:Video or Technical Support
  • Structure:Chain Conveyor
  • Material:Stainless Steel
  • Material Feature:Oil Resistant
  • Application:Mining Transport
  • Condition:New

Base Info

  • Model NO.:Ms32
  • Delivery Volume:50m3,H
  • Material Bulk Density:0.4-0.8
  • Delivery Length:40m
  • Safety Angle:0-15°
  • Chain Spacing:200
  • Chain Pitch:100
  • Roller Diameter:28mm
  • Chain Type:Tg100
  • Transport Package:Wooden
  • Specification:SGD,SGB
  • Trademark:China Coal
  • Origin:China
  • HS Code:8428399000
  • Production Capacity:100

Description

Basic Info.

Model NO. Ms32 Delivery Volume 50m3/H Material Bulk Density 0.4-0.8 Delivery Length 40m Safety Angle 0-15° Chain Spacing 200 Chain Pitch 100 Roller Diameter 28mm Chain Type Tg100 Transport Package Wooden Specification SGD/SGB Trademark China Coal Origin China HS Code 8428399000 Production Capacity 100

Product Description

Introduction Of MS32 Coal Mine Chain Scraper Conveyor

The buried scraper conveyor is a transport device that transports the bulk material to a predetermined target by means of a scraper chain moving within the closed casing. The utility model has the advantages of small volume, strong sealing property, good rigidity, flexible process arrangement, convenient installation and maintenance, multi-point feeding and multi-point discharging. This has significantly improved the working conditions of workers and prevented environmental pollution. The principle of the buried scraper conveyor is dependent on the internal friction and side pressure of the material. During the process of conveying the material, the pressure in the direction of the movement of the scraper chain and the pushing force of the lower material on the upper material during constant feeding are used. The force is synthesized enough to overcome the external frictional resistance generated between the material and the casing when the material is conveyed in the tank and the weight of the material itself. The material can form a continuous stream moving forward regardless of horizontal conveying, inclined conveying and vertical conveying.


Parameter Of MS32 Coal Mine Chain Scraper Conveyor

Delivery volume80m3/h
Material bulk density:0.4-0.8
Delivery length: 40m
Safety angle:0-15°
Chain spacing:200
Chain pitch:100
Roller diameter: 28mm
Chain type:TG100



Photos Of MS32 Coal Mine Chain Scraper Conveyor

Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
Ms32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper ConveyorMs32 Coal Mine Chain Scraper Conveyor Coal Mining Scraper Conveyor
