Hopper Cement Conveyor System Screw Conveyor Machine Lx

Hebei Juntong Machinery Manufacturing Co., Ltd.
  • Structure：Conveyor System
  • Material：Carbon Steel
  • Material Feature：Oil Resistant, Heat Resistant, Fire Resistant
  • Application：Chemical Industry, Grain Transport, Mining Transport, Power Plant
  • Condition：New
  • Load Capacity：78-3000t,H

Base Info

  • Model NO.：CEMA JIS DIN ISO
  • Voltage：380V or as The Clients′ Demand
  • Power(W)：as The Model
  • Certification：ISO Ce ISO SGS BV
  • Belt Speed：0.125-7.1m,S
  • Warranty：One Year
  • Belt Width：400-3000mm
  • Pulley：Drive Pulley and Bend Pulley
  • Length：Customized Size
  • Transport Package：Wooden Box Packing and Pallet Packing
  • Specification：Steel(Q235)
  • Trademark：JTURN
  • Origin：Hengshui
  • HS Code：8431390000
  • Production Capacity：200 Sets Per Month

Description

Model

Belt width

(mm)

Transmission

drum's

diameter

Bend pulley

diameter

Carrier roller's

diameter

Belt speed

(m³/h)

0.811.251.622.53.1544.555.66.5DT II(A)500500250-50089

Conveying

quantity

(m³/h)

6969108139174217      650500-630250-63089-108127159198254318397      800500-1000250-100089-159198248310397496620781     1000630-1600250-1600108-159324405507649811101412781622    1200630-1600250-1600108-159 593742951118814861872237726742971  1400630-1600315-1600108-159 82510321321165220652602330437184130  1600630-1600400-1600133-194    2186273334444373492054666122 1800630-1600400-1600133-194    279534944403559162916989782990832000800-1600500-1600133-194    34704338546669417808867697171127722001000-1600630-1600159-219      68438690977610863121661412024001000-1600800-1600159-219      82891052611842131581473717104



ModelMain motorPower rangeVoltage rangeTransmission connecting formatDT II(A)2.2kw-315kw

380V is applied when the power is less than

200KW while 3KV or 6KV is applied when the

power is more than 200KW

Resilient coupling is adopted when the power is

2.2-37KW while hydraulic coupling is adopted

when the power is 45-315KW
