Cholift Bda 3300lbs-4400lbs Series Semi Electric Pallet Stacker
Ningbo Cholift Forklift Co., Ltd.- Structure：Forklift
- Material：Carbon Steel
- Material Feature：High Strength
- Application：Material Handling Industry
- Condition：New
- Certificates：CE,ISO Semi-Electric Forklift
Base Info
- Model NO.：BDA
- Lift Type：Battery Lift
- Fork Length：900,1070,1150mm
- Warranty：1 Year
- Factory：Ningbo Cholift
- Color：as Per Customer′s Request Semi-Electric Forklift
- Dimension(L*W*H)：1735X800X2085
- Max Lift Height：1.6m,2.0m,2.5m,3.0m,3.5m
- After-Sales Service Provided：Overseas Third-Party Support Available
- Forks：Adjustable Forks, Fixed Foks, Forged Forks
- Drive Type：Manual Drive
- Capacity：1.0t,1.5t and 2.0t
- Certification：CE
- Product Name：Semi-Electric Stacker
- Transport Package：1PC,Pallet
- Specification：BDA1516
- Trademark：CHOLIFT
- Origin：Ningbo, China
- HS Code：84271090
- Production Capacity：500 Set,Sets Per Month
Description
MODEL
BDA
LOAD CAPACITY
Q(kg)
1000/1500/2000
LOAD CENTER
c(mm)
500
WHEEL BASE
Y(mm)
1145
WEIGHT (WITH BATTERY)
kg
265-350
WHEEL SIZE, FRONT
(mm)
φ80x70
WHEEL SIZE, REAR
(mm)
φ180x50
HEIGHT, MAST LOWERED
h1(mm)
2088
LIFTING HEIGHT
h3(mm)
1600/2500/3000/3300/3500
MAST HEIGHT AT MAX. LIFTING HEIGHT
h4(mm)
2088
LOWERED FORK HEIGHT
h13(mm)
90
OVERALL LENGTH
l1(mm)
1505
OVERALL WIDTH
b1(mm)
800(980)
FORK LENGTH
l(mm)
900/1070/1150
FORK WIDTH
b5(mm)
550/660
MAST GROUND CLEARANCE
m1(mm)
28
AISLE WIDTH FOR PALLET1000x1200 (1200 CROSSWAYS)
Ast(mm)
1705
AISLE WIDTH FOR PALLET 800x1200 (1200 LENGTHWAYS)
Ast(mm)
1755
TURNING RADIUS
Wa(mm)
1210
LIFTING SPEED,LADEN/UNLADEN
m/s
135/150
LOWER SPEED,LADEN/UNLADEN
m/s
MANUAL
LIFTING MOTOR POWER
kW
1.6
BATTERY VOLTAGE/NOMINAL CAPACITY
V/Ah
12/(120/135/150)
