Yilun Mining Steel Conveyor Roller
DEZHOU YILUN CONVEYING MACHINERY CO., LTD.- Material：Carbon Steel
- Surface Treatment：Baking Paint
- Belt Width：500-2400(B)
- Bearing No：204 205 305 306 307 308 309
- Weight：2.066kgs
- Color：Red, Blue, Yellow, Black, Ects
Base Info
- Model NO.：D*240*270
- Standards：GB, Cema, DIN, JIS, Etcs
- Seal：Double Labyrinth Seal
- Lenght：220mm-1450mm
- Transport Package：Wooden Case
- Specification：D*240*270
- Trademark：YI LUN
- Origin：China
- HS Code：84313900
- Production Capacity：1500piece,Day
Description
Bearings Type
(Min~Max)Idler's Shell Wall Thickness mm Inch 63.5 2 1/2 150~3500 204 3.0mm~3.75mm 76 3 150~3500 204 205 3.0mm~4.0mm 89 3 1/3 150~3500 204 205 3.0mm~4.0mm 102 4 150~3500 204 205 305 3.5mm~4.0mm 108 4 1/4 150~3500 204 205 305 306 3.5mm~4.0mm 114 4 1/2 150~3500 205 206 305 306 3.5mm~4.5mm 127 5 150~3500 204 205 305 306 3.5mm~4.5mm 133 5 1/4 150~3500 205 206 207 305 306 3.5mm~4.5mm 140 5 1/2 150~3500 205 206 207 305 306 3.5mm~4.5mm 152 6 150~3500 205 206 207 305 306 307 308 4.0mm~4.5mm 159 6 1/4 150~3500 205 206 207 305 306 307 308 4.0mm~4.5mm 165 6 1/2 150~3500 207 305 306 307 308 4.5mm~6.0mm 177.8 7 150~3500 207 306 307 308 309 4.5mm~6.0mm 190.7 7 1/2 150~3500 207 306 307 308 309 4.5mm~6.0mm 194 7 5/8 150~3500 207 307 308 309 310 4.5mm~6.0mm 219 8 5/8 150~3500 308 309 310 4.5mm~6.0mm Name: Conveyor rollers/idlers Material: The normal material is iron, we can also do stainless steel, UHMWPE, and so on Size length and diameter can be customized Bearing as customer requests Roller type carrier rollers, heavy-duty rollers, return rollers, UHMWPE rollers, centering rollers, spiral rollers, and so on Pipe thickness can be customized, 2.5mm, 2.75mm, 3mm, 3.25mm, 3.5mm, 3.75mm, and so on Color produce based on your request
(Min~Max)
