57 Wing Side Guide Roller Idler for Belt Conveyor

DEZHOU YILUN CONVEYING MACHINERY CO., LTD.
  • Material:Iron
  • Application:Mining Transport
  • Structure:Ordinary Roller
  • Bearing Type:Double Sealed Bearing
  • Type:Grooved Conveyor Idler
  • Certification:ISO9001:2015 BV

Base Info

  • Model NO.:57*160
  • Life Time:More Than 50000 Hours
  • Guarantee:1 Year
  • Standards:GB, Cema, DIN, JIS, Etcs
  • Packing:Wooden Box
  • Color:Red, Blue, Yellow, Black, Ects
  • Seal:Double Labyrinth Seal
  • Transport Package:Wooden Box
  • Specification:4"*9"
  • Trademark:Yilun
  • Origin:Shandong, China
  • HS Code:84313900
  • Production Capacity:720000PCS,Year

Description

2213.765309.4753015.2380013.280021.36140021.49140034.98160024.26160039.51
2.Brife introduction for Yilun Conveyor roller1.Material: Steel,rubber
2.Bearing:6204,6205,6305,6306,6307,6308,6309,6310
3.Daimeter: Ø50-Ø219
4.Lenght:120mm-2200mm
5.Seal: double labyrinth seal
5.Workign life:30000-50000hours
6.Standards:GB,CEMA,JIS,DIN,AUSTRALIA
7.Color: mulit-color for choice
57 Wing Side Guide Roller Idler for Belt Conveyor3.Advantages
 57 Wing Side Guide Roller Idler for Belt Conveyor57 Wing Side Guide Roller Idler for Belt ConveyorThe pipe we choose is the high quality welding pipe,the roundness is                                   The shaft we choose is high-precsion rond cold steel,the roundness is
 lower 0.6mm,the straightnesss is 0.15%, the wall thickness tolerance                                 0.8, and the tolerance is only ±0.0065mm, make sure the bearing and
is ±0.1mm, the thickness from 2.5~6.0mm, diaeter is from 50~219mm.                               shaft match closely, the bearing move safely.
0.8,±0.1mm, the thickness from 2.5~6.0mm, diaeter is from 50~219mm.
The pipe is rust removal to increase paint adhesion.
57 Wing Side Guide Roller Idler for Belt Conveyor57 Wing Side Guide Roller Idler for Belt Conveyor
Bearing housing is punched by the superipr steel sheet(SPHC),                      This bearing is the joint ventures, it is the roller special double
After that, we will use the housing circle machine to cut the outside            seal, the bearing inner race have V-groove, grease is also the
of the housing, to make sure the high Concentricity of the roller and           imported grease (Inject the grease into the both sides of the ball
 the small runout.                                                                                                     bearing).
57 Wing Side Guide Roller Idler for Belt Conveyor57 Wing Side Guide Roller Idler for Belt ConveyorThis seal is the national standard double labyrinth seal, 4 pieces                 We can print the brand for the customer requests, but need the
pom and 3 pieces stell seal.Injected the high quality No.2 lithium                 customer give us the authorization.
grease. it is water proof and dustproof,anti-corrosion,wear-resisting,ect...


4.Technical quality team
57 Wing Side Guide Roller Idler for Belt Conveyor
4.Packing & Shipping
we can provide different kinds of packing for the customer.
Wooden box and wooden pallet packing for your choice.
57 Wing Side Guide Roller Idler for Belt Conveyor
5.Certificate
57 Wing Side Guide Roller Idler for Belt Conveyor
6.Customer visiting and the exhibitions
57 Wing Side Guide Roller Idler for Belt Conveyor
6.After sale service

We provide the customer best after sale services, and we solve the problems any time.
57 Wing Side Guide Roller Idler for Belt Conveyor
7.Company introduction
 1.)Dezhou Yilun conveying Machinery Co.,Ltd was founded in 2005.
 2.)It's registered capital is 11.68million CNY and It is private joint-stock enterprise. Our main products are  cnoveyor roller,idler,frame, pulley,belt and belt conveyor system for TD75 ,DTII,DTIIA,CEMA ects.
3.)we has large lathes, numerical control, double pressing machine, double welding machine, double boring  lathe, milling machine, sawing machine and so on. The products have gained various patents. We can produce more than one thousand rollers and ten pulleys per day.
4.)We have the professionalQC dept. to keep the good quality before the  goods sent out.
    The products are sold to Middle East,Africa ,Australia,Europe,Southeast Asia,Russia and some other countries  and regions. We will Strengthen the inner management and improve our products' quality constantly.
   We will offer the best products for customers from the beginning to the end.

8.FAQ



Q: What information do we need to provide to you in order to confirm our conveyor carrying rollers order?

   A: We work with technical drawings for any non-standard products. If the order is for standard parts, you only have to provide us with the part number so we may define the parts of the order.



Q: Do you have the products in stock?

   A: No. All rollers are produced according to your order.



Q: Can you produce the hose with my own brand?

   A: Yes, we have been offering OEM services to famous manufacturer for several years. Please send email to talk about details.



 Q: How does your factory do regarding to quality control?

   A: Quality is priority. Hebei Juming always attach great importance to quality control from beginning to the end of the production. Every batch rollers will be carefully inspected before it's packed for shipment.



Q: Can I order a sample?

   A: Of course. We can offer regular model roller sample for free, but the freight cost shall be borne by your side. If you want customized model sample, we'd like you to bear the charge for sample and freight.



Q: What's benefit will you bring?

   A: Your client satisfied on the quality.

        Your client continued orders.

        Your can get good reputation from your market and obtain more orders.



If you do not see the question you are having, please email us for further assistance.
